| پارامتر مدل |
قطر سوراخ مشترک d1,d2 |
ΦD |
L |
LF |
LP |
d3 |
اس |
اف |
م |
گشتاور پیچ سفت کردن
(NM) |
| GW-19X34 |
3،4،5،6،6.35،7،8 |
19 |
34 |
9.1 |
5.2 |
Φ9 |
1.8 |
3.3 |
M2.5 |
1 |
| GW-26X44.5 |
5,6,6.35,7,8,9,9,525,10,11,12,14 |
26 |
44.5 |
11.65 |
6.5 |
Φ12.5 |
2.6 |
3.9 |
M3 |
1.5 |
| GW-32X54 |
5,6,6.35,7,8,9,9,525,10,11,12,12.7,14,15, |
32 |
54 |
12.25 |
9.5 |
Φ15 |
3.5 |
3.85 |
M3 |
1.5 |
| GW-34X58 |
5,6,6.35,7,8,9,9,525,10,11,12,12,7,14,15,16 |
34 |
58 |
14.25 |
9.5 |
Φ16 |
3.5 |
4.85 |
M4 |
2.5 |
| GW-39X65.5 |
8,9,9,525,10,11,12,12.7,14,15,16,17,18,19 |
39 |
65.5 |
14.9 |
11.2 |
Φ19.3 |
4.5 |
5 |
M4 |
2.5 |
| GW-44X65.5 |
8،9،9.525،10،11،12،12.7،14،15،16،17،18،19،20،
22،24
|
44 |
65.5 |
14.9 |
11.2 |
Φ22.5 |
4.5 |
5 |
M4 |
2.5 |
| GW-50X80 |
8,9,9,525,10,11,12,12.7,14,15,16,17,18,19,
20،22،
24،25
|
50 |
80 |
20.6 |
12.2 |
Φ23 |
4.8 |
6 |
M5 |
7 |
| GW-56X83 |
10,12,14,15,16,17,18,19,20,22,24,25,28,30,32 |
56 |
83 |
19.75 |
13.5 |
Φ32.5 |
5.5 |
6.4 |
M5 |
7 |
| GW-68X97 |
12,14,15,16,17,18,19,20,22,24,25,28,30,32,
35,38
|
68 |
97 |
23.35 |
15.7 |
Φ38.3 |
6.3 |
7.7 |
M6 |
12 |
| GW-82X128 |
17,18,19,20,22,24,25,28,30,32,35,38,40,42 |
82 |
128 |
30 |
22 |
Φ45.5 |
8 |
9.7 |
M8 |
20 |
